| Varenummer | NV140FHM-N66 |
| Mærke | BOE |
| Størrelse | 14.0 |
| Ansøgning | Laptop |
| Løsning | 1920×1080 |
| Sammensætning | LCM , a-Si TFT-LCD |
| Lysstyrke | |
| CR | 800:1 |
| Farver | 16.2M |
| Baggrundsbelysning | 10S5P |
| Interface | eDP |
| fabrikant | BOE |
| modelnavn | NV140FHM-N66 (BOE08B5) |
| skærmstørrelse | 14.0 inch |
| skærmtype | LCM , a-Si TFT-LCD |
| pixel antal | 1920(RGB)×1080 (FHD) 157PPI |
| arrangement | RGB Vertical Stripe |
| aktivt område (mm) | 309.312 × 173.988 (H×V) |
| omrids (mm) | 314.31 × 191.09 × 2.6 (H×V×D) |
| rammeareal (mm) | - |
| behandling | Antiglare, Hard coating (3H) |
| luminans | 300 cd/m² (Typ.) |
| kontrastforhold | 800 : 1 (Typ.) (TM) |
| synsvinkel | 85/85/85/85 (Typ.)(CR≥10) |
| respons | 20 (Typ.)(Tr+Td) ms |
| god udsigt kl | Symmetry |
| arbejdstilstand | ADS, Normally Black, Transmissive |
| farvedybde | 16.2M 100% sRGB |
| baggrundsbelysning | 10S5P WLED , 15K hours , With LED Driver |
| konturform | Slim (PCBA Flat, T≤3.2mm) |
| anvendes til | Laptop |
| opdateringshastighed | 60Hz |
| berøringsskærm | Without |
| signaltype | eDP (2 Lanes) , eDP1.2 , HBR1 (2.7G/lane) , 30 pins Connector |
| spændingsforsyning | 3.3V (Typ.) |
| max. vurderinger | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
