| Varenummer | NV156FHM-N4M |
| Mærke | BOE |
| Størrelse | 15.6 |
| Ansøgning | Laptop |
| Løsning | 1920×1080 |
| Sammensætning | LCM, a-Si TFT-LCD |
| Lysstyrke | |
| CR | 700:1 |
| Farver | 16.2M |
| Baggrundsbelysning | 10S6P |
| Interface | eDP |
| fabrikant | BOE |
| modelnavn | NV156FHM-N4M (BOE081A) 1 Compatible |
| skærmstørrelse | 15.6 inch |
| skærmtype | LCM, a-Si TFT-LCD |
| pixel antal | 1920(RGB)×1080 (FHD) 141PPI |
| arrangement | RGB Vertical Stripe |
| aktivt område (mm) | 344.16 × 193.59 (H×V) |
| omrids (mm) | 350.66 × 205.69 × 5.4 (H×V×D) |
| rammeareal (mm) | - |
| behandling | Antiglare, Hard coating (3H) |
| luminans | 300 cd/m² (Typ.) |
| kontrastforhold | 700 : 1 (Typ.) (TM) |
| synsvinkel | 85/85/85/85 (Typ.)(CR≥10) |
| respons | 30 (Typ.)(Tr+Td) ms |
| god udsigt kl | Symmetry |
| arbejdstilstand | ADS, Normally Black, Transmissive |
| farvedybde | 16.2M 72% NTSC |
| baggrundsbelysning | 10S6P WLED , 15K hours , With LED Driver |
| konturform | Slim (PCBA Bent, T≤3.0mm) |
| anvendes til | Laptop |
| opdateringshastighed | 60Hz |
| berøringsskærm | Without |
| signaltype | eDP (2 Lanes) , eDP1.3 , HBR1 (2.7G/lane) , Connector 30 pins |
| spændingsforsyning | 3.3V (Typ.) |
| max. vurderinger | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| B156XW01 V2 | AUO | 15.6 | 1366×768 |
| LP156WH2-TLG1 | LG Display | 15.6 | 1366×768 |
| LP156WHU-TPG1 | LG Display | 15.6 | 1366×768 |
| N156B6-L07 | Innolux | 15.6 | 1366×768 |
| N156B6-L0B | Innolux | 15.6 | 1366×768 |
| N156BGK-E33 | Innolux | 15.6 | 1366×768 |
| N156O6-L01 | Innolux | 15.6 | 1600×900 |
| NV156FHM-N41 | BOE | 15.6 | 1920×1080 |
| NV156FHM-N42 | BOE | 15.6 | 1920×1080 |
| NV156FHM-N43 | BOE | 15.6 | 1920×1080 |
