| Varenummer | NV156FHM-N43 |
| Mærke | BOE |
| Størrelse | 15.6 |
| Ansøgning | NBPC |
| Løsning | 1920×1080 |
| Sammensætning | LCM |
| Lysstyrke | 300 |
| CR | 800:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | eDP |
| panel mærke | BOE |
| panel model | NV156FHM-N43 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 15.6 inch |
| løsning | 1920(RGB)×1080 , FHD |
| visningstilstand | ADS, Normally Black, Transmissive |
| aktivt område | 334.16×193.59 mm |
| omrids | 359.5×223.8×3.2 mm |
| form stil | Slim (PCBA Flat, Depth ≤3.2mm) |
| overflade | Antiglare |
| lysstyrke | 300 cd/m² (Typ.) |
| kontrastforhold | 800:1 (Typ.) |
| vise farver | 262K (6-bit), CIE193172% |
| responstid | 30 (Typ.)(Tr+Td) |
| synsvinkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 9S6PWLEDEmbedded (LED Driver) |
| signal interface | eDP (2 Lanes), 30 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | NBPC |
| BT156GW01 V.3 | Innolux | 15.6 | 1366×768 |
| LP156WH2-TLQ2 | LG Display | 15.6 | 1366×768 |
| LTN156AT01-A01 | Samsung | 15.6 | 1366×768 |
| LTN156AT05-W01 | Samsung | 15.6 | 1366×768 |
| LTN156AT11-A01 | Samsung | 15.6 | 1366×768 |
| N156BGE-EA1 | Innolux | 15.6 | 1366×768 |
| N156HGE-LA1 | Innolux | 15.6 | 1920×1080 |
| NV156FHM-N41 | BOE | 15.6 | 1920×1080 |
| NV156FHM-N42 | BOE | 15.6 | 1920×1080 |
| NV156FHM-N43 | BOE | 15.6 | 1920×1080 |
| B154EW01 V4 | AUO | 15.4 | 1280×800 |
| CLAA140UA01 CN | CPT | 14.0 | 1600×900 |
| LTN133AT23-001 | Samsung | 13.3 | 1366×768 |
| LTN140AT02-B01 | Samsung | 14.0 | 1366×768 |
| LTN140AT21-W01 | Samsung | 14.0 | 1366×768 |
| LTN141AT13-B01 | Samsung | 14.1 | 1280×800 |
| LTN141W1-L09-1 | Samsung | 14.1 | 1280×800 |
| LTN150PF-L02 | Samsung | 15.0 | 1400×1050 |
| LTN170WA-L01 | Samsung | 17.0 | 1440×900 |
| N133B6-L02 | Innolux | 13.3 | 1366×768 |
