| Varenummer | P236MWF1 R2 |
| Mærke | IVO |
| Størrelse | 23.6 |
| Ansøgning | DMPC |
| Løsning | 1920×1080 |
| Sammensætning | CELL |
| Lysstyrke | 0 |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | No B/L |
| Interface | LVDS |
| panel mærke | IVO |
| panel model | P236MWF1 R2 |
| paneltype | a-Si TFT-LCD , CELL |
| panelstørrelse | 23.6 inch |
| løsning | 1920(RGB)×1080 , FHD |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 521.28×293.22 mm |
| omrids | 534.48×306.42×1.83 mm |
| overflade | Antiglare, Hard coating (3H) |
| glas dybde | 0.70+0.70 mm |
| transmissivitet | 5.45% (Typ.)(with Polarizer) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 16.7M (6-bit + Hi-FRC), CIE193172% |
| responstid | 5 (Typ.)(Tr+Td) |
| synsvinkel | 85/85/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| signal interface | LVDS (2 ch, 8-bit), 30 pins |
| indgangsspænding | 5.0V (Typ.) |
| Ansøgning | DMPC |
