| Varenummer | M201EW02 V0 |
| Mærke | AUO |
| Størrelse | 20.1 |
| Ansøgning | DMPC |
| Løsning | 1680×1050 |
| Sammensætning | LCM |
| Lysstyrke | 300 |
| CR | 800:1 |
| Farver | 16.7M |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | AUO |
| panel model | M201EW02 V0 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 20.1 inch |
| løsning | 1680(RGB)×1050 , WSXGA+ |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 433.44×270.9 mm |
| omrids | 459.4×296.4×23.3 mm |
| overflade | Antiglare, Hard coating (3H) |
| lysstyrke | 300 cd/m² (Typ.) |
| kontrastforhold | 800:1 (Typ.) |
| vise farver | 16.7M (6-bit + Hi-FRC), CIE193172% |
| responstid | 3.6/1.4 (Typ.)(Tr/Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 6 pcsCCFLWithout Driver |
| signal interface | LVDS (2 ch, 8-bit), 30 pins |
| indgangsspænding | 5.0V (Typ.) |
| Ansøgning | DMPC |
| LM201U04-A3 | LG Display | 20.1 | 1600×1200 |
| LQ201U1LW11Z | SHARP | 20.1 | 1600×1200 |
| LQ201U1LW32 | SHARP | 20.1 | 1600×1200 |
| M201EW01 V3 | AUO | 20.1 | 1680×1050 |
| M201EW02 V0 | AUO | 20.1 | 1680×1050 |
| M201EW02 V6 | AUO | 20.1 | 1680×1050 |
| M201EW02 V9 | AUO | 20.1 | 1680×1050 |
| M201EW02 VG | AUO | 20.1 | 1680×1050 |
| M201P1-L03 | Innolux | 20.1 | 1400×1050 |
| LM220WE1-TLM1 | LG Display | 22.0 | 1680×1050 |
| LM230WU3-STC3 | LG Display | 23.0 | 1920×1200 |
| LTM190E4-L02 | Samsung | 19.0 | 1280×1024 |
| M170EG01 V5 | AUO | 17.0 | 1280×1024 |
| M185BGE-P02 | Innolux | 18.5 | 1366×768 |
| M190EN04 V1 | AUO | 19.0 | 1280×1024 |
| M236HJJ-P02 | Innolux | 23.6 | 1920×1080 |
| MT220WW01 V.5 | Innolux | 22.0 | 1680×1050 |
| NL128102BC29-01 | NLT | 19.0 | 1280×1024 |
| TMS190WX1-05TB | Tianma | 19.0 | 1440×900 |
