| Varenummer | P420HVN01.0 |
| Mærke | AUO |
| Størrelse | 42 |
| Ansøgning | PID |
| Løsning | 1920×1080 |
| Sammensætning | LCM |
| Lysstyrke | 700 |
| CR | 4000:1 |
| Farver | 16.7M/1.07B |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | AUO |
| panel model | P420HVN01.0 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 42 inch |
| løsning | 1920(RGB)×1080 , FHD |
| visningstilstand | AMVA3, Normally Black, Transmissive |
| aktivt område | 930.24×523.26 mm |
| omrids | 957.45×550.2×54.2 mm, Videowall Seam 27.2 mm |
| overflade | Antiglare (Haze 11%), Hard coating (3H) |
| lysstyrke | 700 cd/m² (Typ.) |
| kontrastforhold | 4000:1 (Typ.) |
| vise farver | 16.7M/1.07B (8-bit / 8-bit + Dithering), CIE193172% |
| responstid | 8 (Typ.)(G to G) |
| synsvinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 12 pcsCCFLEmbedded (Inverter) |
| signal interface | LVDS (2 ch, 8/10-bit), 51 pins |
| indgangsspænding | 12.0V (Typ.) |
| Ansøgning | PID |
| LC420EUD-SDM1 | LG Display | 42 | 1920×1080 |
| LC420EUF-SDA1 | LG Display | 42 | 1920×1080 |
| LC420EUN-SEF1 | LG Display | 42 | 1920×1080 |
| LC420WUE-SDP1 | LG Display | 42 | 1920×1080 |
| P420HVN01.0 | AUO | 42 | 1920×1080 |
| P420HW01 V1 | AUO | 42 | 1920×1080 |
| P420HW02 V0 | AUO | 42 | 1920×1080 |
| T420HVN04.5 CELL | AUO | 42 | 1920×1080 |
| T420HW04 V3 | AUO | 42 | 1920×1080 |
| T420XW01 V9 | AUO | 42 | 1366×768 |
| LD320WUD-SBA1 | LG Display | 31.5 | 1920×1080 |
| LD420WUB-SCG1 | LG Display | 42 | 1920×1080 |
| LD420WUN-SCA1 | LG Display | 42 | 1920×1080 |
| LTI400HA03 | Samsung | 40 | 1920×1080 |
| LTI460AP01-101 | Samsung | 46 | 1366×768 |
| LTI460HA01 | Samsung | 46 | 1920×1080 |
| LTI460HM01 | Samsung | 46 | 1920×1080 |
| LTI700HD01-006 | Samsung | 70 | 1920×1080 |
| P645HW01 V0 | AUO | 65 | 1920×1080 |
| P650HVN02.6 | AUO | 65 | 1920×1080 |
