| Varenummer | P645HW01 V0 |
| Mærke | AUO |
| Størrelse | 65 |
| Ansøgning | PID |
| Løsning | 1920×1080 |
| Sammensætning | LCM |
| Lysstyrke | 700 |
| CR | 2500:1 |
| Farver | 1.07B |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | AUO |
| panel model | P645HW01 V0 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 65 inch |
| løsning | 1920(RGB)×1080 , FHD |
| visningstilstand | AMVA3, Normally Black, Transmissive |
| aktivt område | 1428.48×803.52 mm |
| omrids | 1482.4×862 mm |
| overflade | Hard coating (3H), Antireflection |
| lysstyrke | 700 cd/m² (Typ.) |
| kontrastforhold | 2500:1 (Typ.) |
| vise farver | 1.07B (10-bit), CIE193172% |
| responstid | 8 (Typ.)(G to G) |
| synsvinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | CCFLEmbedded (Inverter) |
| signal interface | LVDS (2 ch, 10-bit), 51 pins |
| indgangsspænding | 12.0V (Typ.) |
| Ansøgning | PID |
