| Varenummer | T420XW01 V9 |
| Mærke | AUO |
| Størrelse | 42 |
| Ansøgning | LCTV |
| Løsning | 1366×768 |
| Sammensætning | LCM |
| Lysstyrke | 500 |
| CR | 1500:1 |
| Farver | 16.7M |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | AUO |
| panel model | T420XW01 V9 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 42 inch |
| løsning | 1366(RGB)×768 , WXGA |
| visningstilstand | AMVA, Normally Black, Transmissive |
| aktivt område | 930.25×523.01 mm |
| omrids | 983×576 mm |
| overflade | Antiglare (Haze 40%), Hard coating (3H) |
| lysstyrke | 500 cd/m² (Typ.) |
| kontrastforhold | 1500:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193172% |
| responstid | 16/7 (Typ.)(Tr/Td); 6.5 (Typ.)(G to G) |
| synsvinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 18 pcsCCFLWithout Driver |
| signal interface | LVDS (1 ch, 8-bit), 30 pins |
| indgangsspænding | 12.0V (Typ.) |
| Ansøgning | LCTV |
| LC420DUE-SFU1 | LG Display | 42 | 1920×1080 |
| LC420EUF-PFF1 | LG Display | 42 | 1920×1080 |
| LC420EUN-SEF4 | LG Display | 42 | 1920×1080 |
| LC420WU1-SLB1 | LG Display | 42 | 1920×1080 |
| LC420WUN-SCA1 | LG Display | 42 | 1920×1080 |
| P420HW01 V1 | AUO | 42 | 1920×1080 |
| PM42H3000 | COC | 42 | 1024×768 |
| T420XW01 V5 | AUO | 42 | 1366×768 |
| T420XW01 V8 | AUO | 42 | 1366×768 |
| T420XW01 V9 | AUO | 42 | 1366×768 |
| LC230WX3-SLA1 | LG Display | 23.0 | 1366×768 |
| LC650EQD-FGF4 | LG Display | 65 | 3840×2160 |
| LM315TA6A | PANDA | 31.5 | 1366×768 |
| LTY260W2-L06 | Samsung | 26.0 | 1366×768 |
| T315HW07 V0 | AUO | 31.5 | 1920×1080 |
| T370XW02 V6 | AUO | 37 | 1366×768 |
| T500HVN04.6 | AUO | 50 | 1920×1080 |
| T650HVN04.0 | AUO | 65 | 1920×1080 |
| T650QVJ02.0 | AUO | 65 | 3840×2160 |
| V400DJ1-KS5 | Innolux | 40 | 3840×2160 |
