| Varenummer | PD057VU9 |
| Mærke | E Ink |
| Størrelse | 5.7 |
| Ansøgning | IA |
| Løsning | 640×480 |
| Sammensætning | LCM |
| Lysstyrke | 800 |
| CR | 850:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | PVI |
| panel model | PD057VU9 1 Compatible model |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 5.7 inch |
| løsning | 640(RGB)×480 , VGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 116.16×87.12 mm |
| omrids | 135×104.6×10.8 mm |
| overflade | Hard coating (3H) |
| lysstyrke | 800 cd/m² (Typ.) |
| kontrastforhold | 850:1 (Typ.) |
| vise farver | 262K (6-bit) |
| responstid | 3/15 (Typ.)(Tr/Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 9S4PWLEDWithout Driver |
| signal interface | TTL (1 ch, 6-bit), 33 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | IA |
| ET0570B0DHU | EDT | 5.7 | 640×480 |
| G084SN03 V1 | AUO | 8.4 | 800×600 |
| KG057QV1CF-G050 | Kyocera | 5.7 | 320×240 |
| LM065HB1T01 | SHARP | 6.5 | 640×240 |
| LM6Q35 | SHARP | 5.5 | 320×240 |
| LQ060B3DW01 | SHARP | 6.0 | 768×128 |
| LQ104V1DC41 | SHARP | 10.4 | 640×480 |
| LQ121S1LG84 | SHARP | 12.1 | 800×600 |
| NL10276BC13-01C | NLT | 6.5 | 1024×768 |
| RGS32256064YH001 | RiTdisplay | 3.2 | 256×64 |
