| Varenummer | RGS10128032WR003 |
| Mærke | RiTdisplay |
| Størrelse | 1.0 |
| Ansøgning | IA |
| Løsning | 128×32 |
| Sammensætning | OLED |
| Lysstyrke | 120 |
| CR | 2000:1 |
| Farver | Mono(White) |
| Baggrundsbelysning | self |
| Interface | SPI |
| panel mærke | RiTdisplay |
| panel model | RGS10128032WR003 |
| paneltype | PM-OLED , OLED |
| panelstørrelse | 1.0 inch |
| løsning | 128×32 |
| aktivt område | 25.58×6.38 mm |
| omrids | 30.4×14.5×1.71 mm |
| overflade | Antiglare |
| lysstyrke | 120 cd/m² (Typ.) |
| kontrastforhold | 2000 : 1 (Min.) |
| vise farver | Mono(White) (1-bit) |
| synsvinkel | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| frekvens | 105Hz |
| driver ic | COG Built-in SSD1305 |
| signal interface | SPI, 16 pins |
| indgangsspænding | 10/2.7V (Typ.)(VCC/VDD) |
| Ansøgning | IA |
