| Varenummer | RGS11096096FR006 |
| Mærke | RiTdisplay |
| Størrelse | 1.1 |
| Ansøgning | IA |
| Løsning | 96×96 |
| Sammensætning | OLED |
| Lysstyrke | 80 |
| CR | 2000:1 |
| Farver | 65K |
| Baggrundsbelysning | self |
| Interface | CPU/SPI |
| panel mærke | RiTdisplay |
| panel model | RGS11096096FR006 |
| paneltype | PM-OLED , OLED |
| panelstørrelse | 1.1 inch |
| løsning | 96(RGB)×96 |
| aktivt område | 20.135×20.14 mm |
| omrids | 27×30.1×1.31 mm |
| overflade | Antiglare |
| lysstyrke | 80 cd/m² (Typ.) |
| kontrastforhold | 2000 : 1 (Min.) |
| vise farver | 65K |
| synsvinkel | 80/80/80/80 (Min.)(L/R/U/D) |
| frekvens | 105Hz |
| driver ic | COG Built-in SEPS114A |
| signal interface | 8-bit 6800/8080 parallel, 4-wire SPI, 34 pins |
| indgangsspænding | 15/2.8V (Typ.)(VCC/VDD) |
| Ansøgning | IA |
