| Varenummer | AA050ME01 |
| Mærke | Mitsubishi |
| Størrelse | 5.0 |
| Ansøgning | IA |
| Løsning | 800×480 |
| Sammensætning | LCM |
| Lysstyrke | 420 |
| CR | 450:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | Mitsubishi |
| panel model | AA050ME01 1 Compatible model |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 5.0 inch |
| løsning | 800(RGB)×480 , WVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 108×64.8 mm |
| omrids | 118.5×77.8×5.4 mm |
| overflade | Clear, Hard coating (2H) |
| lysstyrke | 420 cd/m² (Typ.) |
| kontrastforhold | 450:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193150% |
| responstid | 5/20 (Typ.)(Tr/Td) |
| synsvinkel | 65/65/65/45 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 2 stringsWLEDWithout Driver |
| signal interface | CMOS (1 ch, 8-bit), 45 pins |
| indgangsspænding | 3.3/5.0V (Typ.)(VCC/AVDD) |
| Ansøgning | IA |
