| Varenummer | RGS18160128FH003 |
| Mærke | RiTdisplay |
| Størrelse | 1.8 |
| Ansøgning | SW |
| Løsning | 160×128 |
| Sammensætning | OLED |
| Lysstyrke | 75 |
| CR | 2000:1 |
| Farver | 65K/262K |
| Baggrundsbelysning | self |
| Interface | CPU/SPI |
| panel mærke | RiTdisplay |
| panel model | RGS18160128FH003 |
| paneltype | PM-OLED , OLED |
| panelstørrelse | 1.8 inch |
| løsning | 160(RGB)×128 |
| aktivt område | 35.015×28.012 mm |
| omrids | 42.7×33.4×2.15 mm |
| overflade | Antiglare |
| lysstyrke | 75 cd/m² (Typ.) |
| kontrastforhold | 2000 : 1 (Min.) |
| vise farver | 65K/262K (6-bit) |
| synsvinkel | 80/80/80/80 (Min.)(L/R/U/D) |
| frekvens | 85Hz |
| driver ic | COF Built-in SSD1353 |
| signal interface | 8/9/16/18-bit 6800/8080 parallel, SPI, 45 pins |
| indgangsspænding | 17/2.8V (Typ.)(VCC/VCI) |
| Ansøgning | SW |
