| Varenummer | SP10Q010 |
| Mærke | KOE |
| Størrelse | 3.8 |
| Ansøgning | IA |
| Løsning | 320×240 |
| Sammensætning | LCM |
| Lysstyrke | 110 |
| CR | 20:1 |
| Farver | Monochrome |
| Baggrundsbelysning | WLED |
| Interface | Parallel Data |
| panel mærke | KOE |
| panel model | SP10Q010 |
| paneltype | FSTN-LCD , LCM |
| panelstørrelse | 3.8 inch |
| løsning | 320×240 , QVGA |
| visningstilstand | STN, Black/White (Negative), Transmissive |
| aktivt område | 76.79×57.59 mm |
| omrids | 94.7×73.3×6 mm |
| overflade | Glare (Haze 0%) |
| lysstyrke | 110 cd/m² (Typ.) |
| kontrastforhold | 20:1 (Typ.) |
| vise farver | Monochrome |
| responstid | 150/350 (Typ.)(Tr/Td) |
| synsvinkel | 80 (Typ.)(CR≥2, Φ2-Φ1)(L/R/U/D) |
| frekvens | 75Hz |
| lampe type | 1S6PWLEDWithout Driver |
| signal interface | Parallel Data (4-bit), 20 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | IA |
