| Varenummer | LS038Y3LX01 |
| Mærke | SHARP |
| Størrelse | 3.8 |
| Ansøgning | MPH |
| Løsning | 480×800 |
| Sammensætning | LCM |
| Lysstyrke | 470 |
| CR | 650:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | MDDI |
| panel mærke | SHARP |
| panel model | LS038Y3LX01 |
| paneltype | CG-Silicon , LCM |
| panelstørrelse | 3.8 inch |
| løsning | 480(RGB)×800 , WVGA |
| visningstilstand | Normally Black, Transflective |
| aktivt område | 49.32×82.2 mm |
| omrids | 53.75×92.49 mm |
| overflade | |
| lysstyrke | 470 cd/m² (Typ.) |
| kontrastforhold | 650:1 (Typ.)(Transmissive) |
| vise farver | 16.7M (8-bit), CIE193190% |
| responstid | 11/24 (Typ.)(Tr/Td) |
| synsvinkel | 80/80/80/70 (Typ.)(CR≥5)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 1S7PWLEDWithout Driver |
| signal interface | MDDI (1 data lane), 30 pins |
| indgangsspænding | 1.8/3.0V (Typ.)(VDDIO/VCC) |
| Ansøgning | MPH |
