| Varenummer | ST5461D01-1 |
| Mærke | CSOT |
| Størrelse | 55 |
| Ansøgning | LCTV |
| Løsning | 3840×2160 |
| Sammensætning | CELL |
| Lysstyrke | 0 |
| CR | 4000:1 |
| Farver | 1.07B |
| Baggrundsbelysning | No B/L |
| Interface | V-by-One |
| panel mærke | CSOT |
| panel model | ST5461D01-1 |
| paneltype | a-Si TFT-LCD , CELL |
| panelstørrelse | 55 inch |
| løsning | 3840(RGB)×2160 , UHD |
| visningstilstand | HVA, Normally Black, Transmissive |
| aktivt område | 1209.6×680.4 mm |
| omrids | 1221.9×692.65 mm |
| overflade | Antiglare (Haze 1.5%), Hard coating (3H) |
| glas dybde | 0.70+0.70 mm |
| transmissivitet | 3.85% (Typ.)(with Polarizer) |
| kontrastforhold | 4000:1 (Typ.) |
| vise farver | 1.07B (8-bit + Hi-FRC), CIE193172% |
| responstid | 6.5 (Typ.)(G to G) |
| synsvinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 120Hz |
| signal interface | V-by-One 8 lane, 51 pins |
| indgangsspænding | 12.0V (Typ.) |
| Ansøgning | LCTV |
| LC550EUB-SCA1 | LG Display | 55 | 1920×1080 |
| LTF550HF01 | Samsung | 55 | 1920×1080 |
| P546HW01 V0 | AUO | 55 | 1920×1080 |
| ST5461B03-1 | CSOT | 55 | 1920×1080 |
| ST5461B05-1 | CSOT | 55 | 1920×1080 |
| ST5461B05-2 | CSOT | 55 | 1920×1080 |
| ST5461D01-1 | CSOT | 55 | 3840×2160 |
| ST5461D04-2 | CSOT | 55 | 3840×2160 |
| T550HVN01.3 CELL | AUO | 55 | 1920×1080 |
| T550QVN02.0 CELL | AUO | 55 | 3840×2160 |
| LC320WUN-SCA2 | LG Display | 31.5 | 1920×1080 |
| LC320WXE-SCC1 | LG Display | 31.5 | 1366×768 |
| LC550EUN-SEM1 | LG Display | 55 | 1920×1080 |
| LK600D3LA3K | SHARP | 60 | 1920×1080 |
| LTA260AP08 | Samsung | 26.0 | 1366×768 |
| LTA460HQ16 | Samsung | 46 | 1920×1080 |
| T315HW07 V6 | AUO | 31.5 | 1920×1080 |
| T420HW07 V7 | AUO | 42 | 1920×1080 |
| T460HW03 VB | AUO | 46 | 1920×1080 |
| V400DK1-KS1 | Innolux | 40 | 3840×2160 |
