| Varenummer | T-51639D084JU-FW-A-AB |
| Mærke | Kyocera |
| Størrelse | 8.4 |
| Ansøgning | IA |
| Løsning | 1024×768 |
| Sammensætning | LCM |
| Lysstyrke | 300 |
| CR | 400:1 |
| Farver | 262K/16.7M |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | OPTREX |
| panel model | T-51639D084JU-FW-A-AB 2 Compatible model |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 8.4 inch |
| løsning | 1024(RGB)×768 , XGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 171.264×128.448 mm |
| omrids | 205×152.4 mm |
| overflade | Antiglare, Hard coating (3H) |
| lysstyrke | 300 cd/m² (Typ.) |
| kontrastforhold | 400:1 (Typ.) |
| vise farver | 262K/16.7M (6-bit / 6-bit + Hi-FRC) |
| responstid | 6/19 (Typ.)(Tr/Td) |
| synsvinkel | 65/65/60/50 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 2 pcsCCFLWithout Driver |
| signal interface | LVDS (1 ch, 6/8-bit), 20 pins |
| indgangsspænding | 3.3V (Typ.) |
| rohs: | |
| Ansøgning | IA |
