| Varenummer | DLH1055 |
| Mærke | LiteMax |
| Størrelse | 10.4 |
| Ansøgning | IA |
| Løsning | 1024×768 |
| Sammensætning | LCM |
| Lysstyrke | 1000 |
| CR | 1200:1 |
| Farver | 16.2M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | LiteMax |
| panel model | DLH1055 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 10.4 inch |
| løsning | 1024(RGB)×768 , XGA |
| visningstilstand | FFS, Normally Black, Transmissive |
| aktivt område | 210.4×157.8 mm |
| omrids | 238.1×173 mm |
| overflade | |
| lysstyrke | 1000 cd/m² (Typ.) |
| kontrastforhold | 1200:1 (Typ.) |
| vise farver | 16.2M (6-bit + FRC) |
| responstid | 40 (Typ.)(Tr+Td) |
| synsvinkel | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| lampe type | WLEDWithout Driver |
| signal interface | LVDS (1 ch, 8-bit), 30 pins |
| Ansøgning | IA |
