| Varenummer | T200XW01 V0 |
| Mærke | AUO |
| Størrelse | 20.0 |
| Ansøgning | LCTV |
| Løsning | 1366×768 |
| Sammensætning | LCM |
| Lysstyrke | 450 |
| CR | 800:1 |
| Farver | 16.7M |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | AUO |
| panel model | T200XW01 V0 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 20.0 inch |
| løsning | 1366(RGB)×768 , WXGA |
| visningstilstand | AMVA, Normally Black, Transmissive |
| aktivt område | 443.609×249.408 mm |
| omrids | 479×278.4 mm |
| overflade | Hard coating (3H) |
| lysstyrke | 450 cd/m² (Typ.) |
| kontrastforhold | 800:1 (Typ.) |
| vise farver | 16.7M (8-bit) |
| responstid | 15/10 (Typ.)(Tr/Td) |
| synsvinkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 6 pcsCCFLWithout Driver |
| signal interface | LVDS (1 ch, 8-bit), 30 pins |
| indgangsspænding | 5.0V (Typ.) |
| Ansøgning | LCTV |
