| Varenummer | TCG121WXLPAPNN-AN20 |
| Mærke | Kyocera |
| Størrelse | 12.1 |
| Ansøgning | IA |
| Løsning | 1280×800 |
| Sammensætning | LCM |
| Lysstyrke | 500 |
| CR | 750:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | Kyocera |
| panel model | TCG121WXLPAPNN-AN20 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 12.1 inch |
| løsning | 1280(RGB)×800 , WXGA |
| visningstilstand | AWV, Normally Black, Transmissive |
| aktivt område | 261.12×163.2 mm |
| omrids | 277.7×182.5 mm |
| overflade | Antiglare |
| lysstyrke | 500 cd/m² (Typ.) |
| kontrastforhold | 750:1 (Typ.) |
| vise farver | 16.7M (6-bit + Hi-FRC) |
| responstid | 18/12 (Typ.)(Tr/Td) |
| synsvinkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDEmbedded (LED Driver) |
| signal interface | LVDS (1 ch, 8-bit), 20 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | IA |
