| Varenummer | NL10276AC24-05 |
| Mærke | NLT |
| Størrelse | 12.1 |
| Ansøgning | DMPC |
| Løsning | 1024×768 |
| Sammensætning | LCM |
| Lysstyrke | 200 |
| CR | 150:1 |
| Farver | Full color |
| Baggrundsbelysning | CCFL |
| Interface | Analog |
| panel mærke | NEC |
| panel model | NL10276AC24-05 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 12.1 inch |
| løsning | 1024(RGB)×768 , XGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 245.76×184.32 mm |
| omrids | 290×225×17 mm |
| overflade | |
| lysstyrke | 200 cd/m² (Typ.) |
| kontrastforhold | 150:1 (Typ.) |
| vise farver | Full color , CIE193140% |
| responstid | 40 (Max.)(Tr) |
| synsvinkel | 50/50/20/20 (Typ.)(CR≥10)(L/R/U/D) |
| lampe type | 2 pcsCCFLEmbedded (Inverter) |
| signal interface | Analog RGB, 31 pins |
| indgangsspænding | 3.3/12V (Typ.)(VCC/VDD) |
| Ansøgning | DMPC |
