| Varenummer | TFD60W12 |
| Mærke | TOSHIBA |
| Størrelse | 6.0 |
| Ansøgning | IA |
| Løsning | 320×234 |
| Sammensætning | LCM |
| Lysstyrke | 280 |
| CR | 80:1 |
| Farver | Full color |
| Baggrundsbelysning | CCFL |
| Interface | Analog |
| panel mærke | TOSHIBA |
| panel model | TFD60W12 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 6.0 inch |
| løsning | 320(RGB)×234 |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 121.92×89.154 mm |
| omrids | 144×109.4 mm |
| overflade | |
| lysstyrke | 280 cd/m² (Typ.) |
| kontrastforhold | 80:1 (Typ.) |
| vise farver | Full color |
| responstid | 70/40 (Max.)(Tr/Td) |
| synsvinkel | 45/45/45/15 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 1 pcsCCFLWithout Driver |
| signal interface | TFT Specific Analog RGB, 24 pins |
| indgangsspænding | 5.0/13.0/23.0/-5.0V (Typ.)(VDD/VBB/VGG/VEE) |
| Ansøgning | IA |
