| Varenummer | TV096WXM-NS0 |
| Mærke | BOE |
| Størrelse | 9.6 |
| Ansøgning | PAD |
| Løsning | 800×1280 |
| Sammensætning | LCM |
| Lysstyrke | 450 |
| CR | 900:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | MIPI |
| panel mærke | BOE |
| panel model | TV096WXM-NS0 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 9.6 inch |
| løsning | 800(RGB)×1280 , WXGA |
| visningstilstand | ADS, Normally Black, Transmissive |
| aktivt område | 129×206.4 mm |
| omrids | 136.7×217×4.65 mm |
| overflade | Hard coating, Antireflection |
| lysstyrke | 450 cd/m² (Typ.) |
| kontrastforhold | 900:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193147% |
| responstid | |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 7S4PWLEDWithout Driver |
| signal interface | MIPI (4 data lanes), 34 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | PAD |
