| Varenummer | B101EAN01.7 |
| Mærke | AUO |
| Størrelse | 10.1 |
| Ansøgning | PAD |
| Løsning | 1280×800 |
| Sammensætning | LCM |
| Lysstyrke | 400 |
| CR | 800:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | MIPI |
| panel mærke | AUO |
| panel model | B101EAN01.7 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 10.1 inch |
| løsning | 1280(RGB)×800 , WXGA |
| visningstilstand | AHVA, Normally Black, Transmissive |
| aktivt område | 216.96×135.6 mm |
| omrids | 227.9×147.8×4.6 mm |
| overflade | Glare (Haze 0%) |
| lysstyrke | 400 cd/m² (Typ.) |
| kontrastforhold | 800:1 (Typ.) |
| vise farver | 16.7M (6-bit + Hi-FRC), CIE193150% |
| responstid | 30 (Typ.)(Tr+Td) |
| synsvinkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 6S4PWLEDEmbedded (LED Driver) |
| signal interface | MIPI (4 data lanes), 34 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | PAD |
| B101EAN01.1 | AUO | 10.1 | 1280×800 |
| B101EAN01.2 | AUO | 10.1 | 1280×800 |
| B101EAN01.4 | AUO | 10.1 | 1280×800 |
| B101EAN02.2 | AUO | 10.1 | 800×1280 |
| B101EVN06.1 | AUO | 10.1 | 1280×800 |
| B101EVT03.1 | AUO | 10.1 | 1280×800 |
| B101EW01 V0 | AUO | 10.1 | 1280×720 |
| B101EW02 V0 | AUO | 10.1 | 1280×720 |
| B101EW02 V1 | AUO | 10.1 | 1280×720 |
| B101EW04 V0 | AUO | 10.1 | 1280×800 |
| B080XAN03.0 | AUO | 7.9 | 768×1024 |
| B101UAN01.1 | AUO | 10.1 | 1920×1200 |
| CLAA101FP05 | CPT | 10.1 | 1920×1200 |
| CLAA101FP05 XG | CPT | 10.1 | 1920×1200 |
| LQ079L1SX01 | SHARP | 7.9 | 1536×2048 |
| LT121DKXBF00 | TOSHIBA | 12.1 | 1280×800 |
| M101NWWB R6 | IVO | 10.1 | 1280×800 |
| N070ICE-GB1 | Innolux | 7.0 | 800×1280 |
| TPF0702001N | JDI | 7.0 | 1200×1920 |
| VVX11F009G00 | Panasonic | 11.6 | 1920×1080 |
