| Varenummer | TX16D18VM2CAB |
| Mærke | KOE |
| Størrelse | 6.2 |
| Ansøgning | IA |
| Løsning | 800×300 |
| Sammensætning | LCM |
| Lysstyrke | 350 |
| CR | 200:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | HITACHI |
| panel model | TX16D18VM2CAB |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 6.2 inch |
| løsning | 800(RGB)×300 , HSVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 148.8×53.76 mm |
| omrids | 173×70 mm |
| overflade | |
| lysstyrke | 350 cd/m² (Typ.) |
| kontrastforhold | 200:1 (Typ.) |
| vise farver | 262K (6-bit), CIE193160% |
| responstid | 45 (Typ.)(Tr+Td) |
| synsvinkel | 70/70/50/80 (Typ.)(CR≥5)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 3S7PWLEDWithout Driver |
| signal interface | CMOS (1 ch, 6-bit), 40 pins |
| indgangsspænding | 3.3V (Typ.)(VDD) |
| Ansøgning | IA |
| AA070ME01-DA1 | Mitsubishi | 7.0 | 800×480 |
| AA121SL01 | Mitsubishi | 12.1 | 800×600 |
| AA121XJ02 | Mitsubishi | 12.1 | 1024×768 |
| G084SN02 V0 | AUO | 8.4 | 800×600 |
| G104XVN01.0 | AUO | 10.4 | 1024×768 |
| KCB104VG2CA-G43 | Kyocera | 10.4 | 640×480 |
| LM24014H | SHARP | 5.2 | 240×64 |
| NL10276BC24-13 | NLT | 12.1 | 1024×768 |
| NL10276BC24-19D | NLT | 12.1 | 1024×768 |
| SP14Q002-A1 | KOE | 5.7 | 320×240 |
