| Varenummer | UG-9664HLBAG01 |
| Mærke | WiseChip |
| Størrelse | 0.95 |
| Ansøgning | IA |
| Løsning | 96×64 |
| Sammensætning | OLED |
| Lysstyrke | 80 |
| CR | 2000:1 |
| Farver | Mono(Blue) |
| Baggrundsbelysning | self |
| Interface | CPU/SPI/I²C |
| panel mærke | WiseChip |
| panel model | UG-9664HLBAG01 |
| paneltype | PM-OLED , OLED |
| panelstørrelse | 0.95 inch |
| løsning | 96×64 |
| aktivt område | 19.95×13.42 mm |
| omrids | 24.9×22.95×1.5 mm |
| overflade | |
| lysstyrke | 80 cd/m² (Typ.) |
| kontrastforhold | 2000 : 1 (Typ.) |
| vise farver | Mono(Blue) (1-bit) |
| synsvinkel | 80/80/80/80 (Min.)(L/R/U/D) |
| driver ic | COG Built-in SSD1305 |
| signal interface | 8-bit 6800/8080 parallel, 4-wire SPI, I²C, 25 pins |
| indgangsspænding | 2.8/1.8/11V (Typ.)(VDD/VDDIO/VCC) |
| rohs: | |
| Ansøgning | IA |
