| Varenummer | A050BTS30R0 |
| Mærke | Aptus |
| Størrelse | 5.0 |
| Ansøgning | IA |
| Løsning | 480×480 |
| Sammensætning | LCM |
| Lysstyrke | 1200 |
| CR | 500:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | Aptus |
| panel model | A050BTS30R0 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 5.0 inch |
| løsning | 480(RGB)×480 |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 87.3×87.3 mm |
| omrids | 111.55×110 mm |
| overflade | |
| lysstyrke | 1200 cd/m² (Typ.) |
| kontrastforhold | 500:1 (Typ.) |
| vise farver | 262K (6-bit) |
| responstid | 25 (Typ.)(Tr+Td) |
| synsvinkel | 50/50/40/40 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDWithout Driver |
| signal interface | TTL (1 ch, 6-bit), 60 pins |
| indgangsspænding | 3.3/9.7/18/-6V (Typ.)(VDD1/VDD2/VGG/VEE) |
| Ansøgning | IA |
