| Varenummer | UG-9616TSWBG01 |
| Mærke | WiseChip |
| Størrelse | 0.84 |
| Ansøgning | IA |
| Løsning | 96×16 |
| Sammensætning | OLED |
| Lysstyrke | 120 |
| CR | 10000:1 |
| Farver | Mono(White) |
| Baggrundsbelysning | self |
| Interface | I²C |
| panel mærke | WiseChip |
| panel model | UG-9616TSWBG01 |
| paneltype | PM-OLED , OLED |
| panelstørrelse | 0.84 inch |
| løsning | 96×16 |
| aktivt område | 21.104×3.504 mm |
| omrids | 29.1×9.2×1.4 mm |
| overflade | |
| lysstyrke | 120 cd/m² (Typ.) |
| kontrastforhold | 10000 : 1 (Typ.) |
| vise farver | Mono(White) (1-bit) |
| synsvinkel | |
| driver ic | Built-in SSD1306 |
| signal interface | I²C, 14 pins |
| indgangsspænding | 2.8/7.25V (Typ.)(VDD/VCC) |
| Ansøgning | IA |
