| Varenummer | VVX13F009G10 |
| Mærke | Panasonic |
| Størrelse | 13.3 |
| Ansøgning | NBPC |
| Løsning | 1920×1080 |
| Sammensætning | LCM |
| Lysstyrke | 400 |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | eDP |
| panel mærke | Panasonic |
| panel model | VVX13F009G10 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 13.3 inch |
| løsning | 1920(RGB)×1080 , FHD |
| visningstilstand | IPS, Normally Black, Transmissive |
| aktivt område | 294.336×165.564 mm |
| omrids | 306.336×187.924×2.58 mm |
| form stil | Slim (PCBA Flat, Depth ≤3.2mm) |
| overflade | Antiglare |
| lysstyrke | 400 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193172% |
| responstid | 26 (Typ.)(Tr+Td) |
| synsvinkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 8S5PWLEDEmbedded (LED Driver) |
| signal interface | eDP (2 Lanes), 30 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | NBPC |
| B133EW01 V9 | AUO | 13.3 | 1280×800 |
| B133EW05 V0 | AUO | 13.3 | 1280×800 |
| HN133WU3-100 | BOE | 13.3 | 1920×1080 |
| LP133WH2-TLA3 | LG Display | 13.3 | 1366×768 |
| LP133WX1-TLC1 | LG Display | 13.3 | 1280×800 |
| LTD133KX2S | TOSHIBA | 13.3 | 1280×800 |
| LTN133AT05-001 | Samsung | 13.3 | 1280×800 |
| LTN133AT17-W01 | Samsung | 13.3 | 1366×768 |
| LTN133AT23-B01 | Samsung | 13.3 | 1366×768 |
| VVX13F009G10 | Panasonic | 13.3 | 1920×1080 |
| B121EW03 V7 | AUO | 12.1 | 1280×800 |
| B121EW08 V0 | AUO | 12.1 | 1280×800 |
| HB125WX1-200 | BOE | 12.5 | 1366×768 |
| LP145WH1-TLA1 | LG Display | 14.5 | 1366×768 |
| LP156WH2-TLAA | LG Display | 15.6 | 1366×768 |
| LQ108M1JW01 | SHARP | 10.8 | 1920×1080 |
| LTD111EWAX | TOSHIBA | 11.1 | 1366×768 |
| LTD141EC7B | TOSHIBA | 14.1 | 1024×768 |
| N154C6-L04 | Innolux | 15.4 | 1440×900 |
| TM121SV-02L01 | SANYO | 12.1 | 800×600 |
