| Varenummer | WEA012864DLPP3N00003 |
| Mærke | Winstar |
| Størrelse | 0.96 |
| Ansøgning | Instruments & Meters |
| Løsning | 128×64 |
| Sammensætning | OLED , PM-OLED |
| Lysstyrke | |
| CR | |
| Farver | Mono(Yellow) |
| Baggrundsbelysning | self |
| Interface | 4-wire |
| fabrikant | Winstar |
| skærmstørrelse | 0.96 inch |
| pixel antal | 128×64 149PPI |
| aktivt område (mm) | 21.74 × 10.86 (H×V) |
| rammeareal (mm) | 23.94 × 12.06 (H×V) |
| synsvinkel | - |
| god udsigt kl | Symmetry |
| farvedybde | Mono(Yellow) |
| masse | - |
| opdateringshastighed | - |
| driver ic liste | Built-in COG SSD1306BZ |
| signaltype | 4-wire SPI, I²C , 8 pins PIN |
| spændingsforsyning | 3.3/5.0/7.5V (Typ.) |
| max. vurderinger | Storage Temp.: -40 ~ 85 °C Operating Temp.: -40 ~ 80 °C |
| modelnavn | WEA012864DLPP3N00003 |
| skærmtype | OLED , PM-OLED |
| arrangement | Rectangle |
| omrids (mm) | 38 × 28.5 × 4.37 (H×V×D) |
| behandling | - |
| respons | - |
| arbejdstilstand | - |
| baggrundsbelysning | self |
| anvendes til | Instruments & Meters |
| berøringsskærm | Without |
