| Varenummer | A056VN01 V0 |
| Mærke | AUO |
| Størrelse | 5.6 |
| Ansøgning | |
| Løsning | 640×480 |
| Sammensætning | LCM |
| Lysstyrke | 350 |
| CR | 400:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | AUO |
| panel model | A056VN01 V0 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 5.6 inch |
| løsning | 640(RGB)×480 , VGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 112.8×84.6 mm |
| omrids | 126.5×100 mm |
| overflade | Antiglare |
| lysstyrke | 350 cd/m² (Typ.) |
| kontrastforhold | 400:1 (Typ.) |
| vise farver | 262K (6-bit) |
| responstid | 15/25 (Typ.)(Tr/Td) |
| synsvinkel | 65/65/45/65 (Typ.)(CR≥10)(L/R/U/D) |
| lampe type | 3S7PWLEDEmbedded (LED Driver) |
| signal interface | Parallel RGB (1 ch, 6-bit) + SPI, 40 pins |
| indgangsspænding | 3.3V (Typ.)(VDD) |
