| Varenummer | LQ056A3AG01 |
| Mærke | SHARP |
| Størrelse | 5.6 |
| Ansøgning | |
| Løsning | 320×234 |
| Sammensætning | LCM |
| Lysstyrke | 250 |
| CR | 60:1 |
| Farver | Full color |
| Baggrundsbelysning | CCFL |
| Interface | Analog |
| panel mærke | SHARP |
| panel model | LQ056A3AG01 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 5.6 inch |
| løsning | 320(RGB)×234 |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 114.2×83.5 mm |
| omrids | 140×102.7 mm |
| overflade | |
| lysstyrke | 250 cd/m² (Typ.) |
| kontrastforhold | 60:1 (Min.) |
| vise farver | Full color |
| responstid | 15/20 (Typ.)(Tr/Td) |
| synsvinkel | 65/65/40/65 (Typ.)(CR≥5)(L/R/U/D) |
| lampe type | 1 pcsCCFLEmbedded (Inverter) |
| signal interface | Analog RGB + Composite Video (NTSC/PAL), 24 pins |
| indgangsspænding | 12.0V (Typ.) |
