| Varenummer | HV056WX1-101 |
| Mærke | HYDIS |
| Størrelse | 5.6 |
| Ansøgning | UMPC |
| Løsning | 1280×800 |
| Sammensætning | LCM |
| Lysstyrke | 300 |
| CR | 500:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | HYDIS |
| panel model | HV056WX1-101 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 5.6 inch |
| løsning | 1280(RGB)×800 , WXGA |
| visningstilstand | HFFS, Normally Black, Transmissive |
| aktivt område | 120.96×75.6 mm |
| omrids | 131.7×87.7×5 mm |
| overflade | |
| lysstyrke | 300 cd/m² (Typ.) |
| kontrastforhold | 500:1 (Typ.) |
| vise farver | 262K (6-bit) |
| responstid | 30 (Typ.)(Tr+Td) |
| synsvinkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 8S2PWLEDEmbedded (LED Driver) |
| signal interface | LVDS (1 ch, 6-bit), 25 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | UMPC |
