| Varenummer | A101AIE40L0 |
| Mærke | Aptus |
| Størrelse | 10.1 |
| Ansøgning | IA |
| Løsning | 1280×720 |
| Sammensætning | LCM |
| Lysstyrke | 500 |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | Aptus |
| panel model | A101AIE40L0 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 10.1 inch |
| løsning | 1280(RGB)×720 , WXGA |
| visningstilstand | AHVA, Normally Black, Transmissive |
| aktivt område | 223.68×125.82 mm |
| omrids | 238.6×148 mm |
| overflade | |
| lysstyrke | 500 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 16.7M (6-bit + Hi-FRC) |
| responstid | 40 (Max.)(Tr+Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 9S3PWLEDWithout Driver |
| signal interface | LVDS (1 ch, 8-bit), 40 pins |
| indgangsspænding | 3.3/3.3V (Typ.)(VDD/AVDD) |
| Ansøgning | IA |
