| Varenummer | G084SN05 V5 |
| Mærke | AUO |
| Størrelse | 8.4 |
| Ansøgning | IA |
| Løsning | 800×600 |
| Sammensætning | LCM |
| Lysstyrke | 350 |
| CR | 500:1 |
| Farver | 262K |
| Baggrundsbelysning | CCFL |
| Interface | Analog + Digital |
| panel mærke | AUO |
| panel model | G084SN05 V5 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 8.4 inch |
| løsning | 800(RGB)×600 , SVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 170.4×127.8 mm |
| omrids | 203×142.5×12.7 mm |
| overflade | |
| lysstyrke | 350 cd/m² (Typ.) |
| kontrastforhold | 500:1 (Typ.) |
| vise farver | 262K (6-bit) |
| responstid | 10/25 (Typ.)(Tr/Td) |
| synsvinkel | 60/60/60/40 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 2 pcsCCFLWithout Driver |
| signal interface | Analog RGB + TTL (1 ch, 6-bit), 45 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | IA |
| G084SN02 V0 | AUO | 8.4 | 800×600 |
| G084SN03 V0 | AUO | 8.4 | 800×600 |
| G084SN03 V1 | AUO | 8.4 | 800×600 |
| G084SN03 V2 | AUO | 8.4 | 800×600 |
| G084SN03 V3 | AUO | 8.4 | 800×600 |
| G084SN05 V3 | AUO | 8.4 | 800×600 |
| G084SN05 V5 | AUO | 8.4 | 800×600 |
| G084SN05 V7 | AUO | 8.4 | 800×600 |
| G084SN05 V8 | AUO | 8.4 | 800×600 |
| G084SN05 V9 | AUO | 8.4 | 800×600 |
| AM-320240N1TMQW-T30H-D(R) | AMPIRE | 5.7 | 320×240 |
| EL240.128.45 CC | Lumineq | 4.8 | 240×128 |
| KL6448USTS-FFW | Kyocera | 6.9 | 640×480 |
| KS3224ASTT-FW-X20 | Kyocera | 5.7 | 320×240 |
| LB121S03-TL03 | LG Display | 12.1 | 800×600 |
| LQ121S1LG79 | SHARP | 12.1 | 800×600 |
| NL8060BC21-11C | NLT | 8.4 | 800×600 |
| OEL9M0065-W-E | Other | 2.7 | 256×64 |
| TFD50W72MS | TOSHIBA | 5.0 | |
| UG-2832TLBGG01 | WiseChip | 1.0 | 128×32 |
