| Varenummer | AA057VF12 |
| Mærke | Mitsubishi |
| Størrelse | 5.7 |
| Ansøgning | IA |
| Løsning | 640×480 |
| Sammensætning | LCM |
| Lysstyrke | 1100 |
| CR | 600:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | Mitsubishi |
| panel model | AA057VF12 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 5.7 inch |
| løsning | 640(RGB)×480 , VGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 115.2×86.4 mm |
| omrids | 135×104.6×9.35 mm |
| overflade | Clear, Hard coating (3H) |
| lysstyrke | 1100 cd/m² (Typ.) |
| kontrastforhold | 600:1 (Typ.) |
| vise farver | 262K (6-bit), CIE193150% |
| responstid | 5/20 (Typ.)(Tr/Td) |
| synsvinkel | 80/80/80/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDEmbedded (LED Driver) |
| signal interface | CMOS (1 ch, 6-bit), 33 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | IA |
| AA050ME01 | Mitsubishi | 5.0 | 800×480 |
| AA050ME01--T1 | Mitsubishi | 5.0 | 800×480 |
| AA050MG01 | Mitsubishi | 5.0 | 800×480 |
| AA057QD01 | Mitsubishi | 5.7 | 320×240 |
| AA057VF12 | Mitsubishi | 5.7 | 640×480 |
| AA057VG02 | Mitsubishi | 5.7 | 640×480 |
| AA057VG12 | Mitsubishi | 5.7 | 640×480 |
| C555001 | SII | 5.7 | 320×240 |
| EL320.240.36 HB SE | PLANAR | 5.7 | 320×240 |
| LQ057Q3DC03 | SHARP | 5.7 | 320×240 |
| ET057007DMU | EDT | 5.7 | 640×480 |
| FX050700DSCWDG12 | Data Image | 5.7 | |
| G057AGE-T01 | Innolux | 5.7 | 320×240 |
| KCS072VG1MF-G40 | Kyocera | 7.2 | 640×480 |
| LM32019T | SHARP | 5.7 | 320×240 |
| LQ121S1LG79 | SHARP | 12.1 | 800×600 |
| LT085AC18N00 | TOSHIBA | 8.5 | 800×480 |
| TX18D11VM1CAA | KOE | 7.0 | 800×480 |
| TX26D12VM0APA | KOE | 10.4 | 800×600 |
| UG-2864KLBMG01 | WiseChip | 1.54 | 128×64 |
