| Varenummer | AA057QD01 |
| Mærke | Mitsubishi |
| Størrelse | 5.7 |
| Ansøgning | IA |
| Løsning | 320×240 |
| Sammensætning | LCM |
| Lysstyrke | 450 |
| CR | 800:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | Mitsubishi |
| panel model | AA057QD01 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 5.7 inch |
| løsning | 320(RGB)×240 , QVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 115.2×86.4 mm |
| omrids | 144×104.6×9.3 mm |
| overflade | Clear, Hard coating (3H) |
| lysstyrke | 450 cd/m² (Typ.) |
| kontrastforhold | 800:1 (Typ.) |
| vise farver | 262K (6-bit), CIE193150% |
| responstid | 8/22 (Typ.)(Tr/Td) |
| synsvinkel | 80/80/80/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDEmbedded (LED Driver) |
| signal interface | CMOS (1 ch, 6-bit), 33 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | IA |
| AA050ME01 | Mitsubishi | 5.0 | 800×480 |
| AA050ME01--T1 | Mitsubishi | 5.0 | 800×480 |
| AA050MG01 | Mitsubishi | 5.0 | 800×480 |
| AA057QD01 | Mitsubishi | 5.7 | 320×240 |
| AA057VF12 | Mitsubishi | 5.7 | 640×480 |
| AA057VG02 | Mitsubishi | 5.7 | 640×480 |
| AA057VG12 | Mitsubishi | 5.7 | 640×480 |
| AM-640480G2TNQW-31H | AMPIRE | 5.7 | 640×480 |
| AM-640480GFTNQW-T01H-L | AMPIRE | 5.7 | 640×480 |
| KCS057QV1AJ-G32 | Kyocera | 5.7 | 320×240 |
| AA104VC10 | Mitsubishi | 10.4 | 640×480 |
| AM-800480LTMQW-W0H | AMPIRE | 5.0 | 800×480 |
| LB104S01-TL02 | LG Display | 10.4 | 800×600 |
| LQ150X1LG55 | SHARP | 15.0 | 1024×768 |
| LTM08C343S | TOSHIBA | 8.4 | 800×600 |
| NL10276BC30-38B | NLT | 15.0 | 1024×768 |
| NL6448BC33-59D | NLT | 10.4 | 640×480 |
| NL8060BC31-42D | NLT | 12.1 | 800×600 |
| RGS10096064FR020 | RiTdisplay | 0.95 | 96×64 |
| TX38D25VM0CAA | KOE | 14.9 | 1280×242 |
