| Varenummer | AA104VC04 |
| Mærke | Mitsubishi |
| Størrelse | 10.4 |
| Ansøgning | IA |
| Løsning | 640×480 |
| Sammensætning | LCM |
| Lysstyrke | 430 |
| CR | 500:1 |
| Farver | 262K |
| Baggrundsbelysning | CCFL |
| Interface | TTL |
| panel mærke | Mitsubishi |
| panel model | AA104VC04 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 10.4 inch |
| løsning | 640(RGB)×480 , VGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 211.2×158.4 mm |
| omrids | 243×181.6×12.7 mm |
| overflade | Antiglare, Hard coating (3H) |
| lysstyrke | 430 cd/m² (Typ.) |
| kontrastforhold | 500:1 (Typ.) |
| vise farver | 262K (6-bit) |
| responstid | 6/19 (Typ.)(Tr/Td) |
| synsvinkel | 65/65/45/65 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 2 pcsCCFLWithout Driver |
| signal interface | CMOS (1 ch, 6-bit), 31 pins |
| indgangsspænding | 3.3V (Typ.)(VCC) |
| Ansøgning | IA |
| AA104SG04 | Mitsubishi | 10.4 | 800×600 |
| AA104VC01 | Mitsubishi | 10.4 | 640×480 |
| AA104VC02 | Mitsubishi | 10.4 | 640×480 |
| AA104VC04 | Mitsubishi | 10.4 | 640×480 |
| AA104VC06 | Mitsubishi | 10.4 | 640×480 |
| AA104VH01 | Mitsubishi | 10.4 | 640×480 |
| AA104VH02 | Mitsubishi | 10.4 | 640×480 |
| AA104XD12 | Mitsubishi | 10.4 | 1024×768 |
| AA104XD12--G1 | Mitsubishi | 10.4 | 1024×768 |
| AA106TA01 | Mitsubishi | 10.6 | 1280×768 |
| AG-320240A4FIQW-K9H-S(N)(R) | AMPIRE | 5.7 | 320×240 |
| CLAA150XP06CW | CPT | 15.0 | 1024×768 |
| EL160.80.50 ET | Lumineq | 3.5 | 160×80 |
| ER0570B2NC6 | EDT | 5.7 | 320×240 |
| LM340UW1-SSA1 | LG Display | 34 | 3440×1440 |
| LM64P101R | SHARP | 7.2 | 640×480 |
| LQ150X1LW72 | SHARP | 15.0 | 1024×768 |
| NL12876BC26-25 | NLT | 15.3 | 1280×768 |
| NL6448BC33-64R | NLT | 10.4 | 640×480 |
| TM057KDH01 | Tianma | 5.7 | 320×240 |
