| Varenummer | AM-1024600K5TMQW-01H |
| Mærke | AMPIRE |
| Størrelse | 7.0 |
| Ansøgning | Industrial Outdoor H |
| Løsning | 1024×600 |
| Sammensætning | LCM , a-Si TFT-LCD |
| Lysstyrke | |
| CR | 700:1 |
| Farver | 16.7M |
| Baggrundsbelysning | 8S3P |
| Interface | LVDS |
| fabrikant | AMPIRE |
| skærmstørrelse | 7.0 inch |
| pixel antal | 1024(RGB)×600 (WSVGA) 169PPI |
| aktivt område (mm) | 153.6 × 90 (H×V) |
| rammeareal (mm) | 156.2 × 92.6 (H×V) |
| luminans | 1000 cd/m² (Typ.) |
| synsvinkel | 75/75/70/75 (Typ.)(CR≥10) |
| god udsigt kl | - |
| farvedybde | 16.7M |
| masse | TBD |
| opdateringshastighed | 60Hz |
| signaltype | LVDS (1 ch, 8-bit) , 20 pins Connector |
| spændingsforsyning | 3.3V (Typ.) |
| max. vurderinger | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| modelnavn | AM-1024600K5TMQW-01H |
| skærmtype | LCM , a-Si TFT-LCD |
| arrangement | RGB Vertical Stripe |
| omrids (mm) | 165.5 × 104.44 × 9.46 (H×V×D) |
| behandling | Glare (Haze 0%), Hard coating |
| kontrastforhold | 700 : 1 (Typ.) (TM) |
| respons | 20/20 (Typ.)(Tr/Td) ms |
| arbejdstilstand | TN, Normally White, Transmissive |
| baggrundsbelysning | 8S3P WLED , 50K hours , With LED Driver |
| anvendes til | Industrial Outdoor High Brightness |
| berøringsskærm | Without |
