| Varenummer | AM-1024600L7TMQW-T05H |
| Mærke | AMPIRE |
| Størrelse | 10.1 |
| Ansøgning | IA |
| Løsning | 1024×600 |
| Sammensætning | LCM |
| Lysstyrke | 440 |
| CR | 500:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | AMPIRE |
| panel model | AM-1024600L7TMQW-T05H |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 10.1 inch |
| løsning | 1024(RGB)×600 , WSVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 222.72×125.28 mm |
| omrids | 235×145.8×10.3 mm |
| overflade | |
| lysstyrke | 440 cd/m² (Typ.) |
| kontrastforhold | 500:1 (Typ.) |
| vise farver | 262K (6-bit) |
| responstid | 5/20 (Typ.)(Tr/Td) |
| synsvinkel | 70/70/70/50 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 6S6PWLEDOptional |
| signal interface | LVDS (1 ch, 6-bit), 30 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | IA |
| AM-1024600-070H | Other | 7.0 | 1024×600 |
| AM-1024600KTMQW-01H | AMPIRE | 7.0 | 1024×600 |
| AM-1024600KTMQW-04H | AMPIRE | 7.0 | 1024×600 |
| AM-1024600L3TMQW-T05H | AMPIRE | 10.1 | 1024×600 |
| AM-1024600L7TMQW-T05H | AMPIRE | 10.1 | 1024×600 |
| B101EW05 V0 | AUO | 10.1 | 1280×800 |
| EJ101IA-01C | Innolux | 10.1 | 1280×800 |
| HSD101PUW1-A00 | HannStar | 10.1 | 1920×1200 |
| N101BGE-L21 | Innolux | 10.1 | 1366×768 |
| N101ICG-L21 Rev.B1 | Innolux | 10.1 | 1280×800 |
| AA121SU01 | Mitsubishi | 12.1 | 800×600 |
| AM-1024600L3TMQW-T05H | AMPIRE | 10.1 | 1024×600 |
| DLC0570BDG-T-2 | Other | 5.7 | 640×480 |
| G104SN05 V0 | AUO | 10.4 | 800×600 |
| G215HVN01.0 S03 | AUO | 21.5 | 1920×1080 |
| LM8V311 | SHARP | 7.7 | 640×480 |
| NL3224BC35-20R | NLT | 5.5 | 320×240 |
| NL6448BC33-50 | NLT | 10.4 | 640×480 |
| TX38D01VM1AAA | KOE | 15.0 | 1024×768 |
| TX38D18VM2BAA REV.B | KOE | 15.0 | 1024×768 |
