| Varenummer | LP097X02-SLQE |
| Mærke | LG Display |
| Størrelse | 9.7 |
| Ansøgning | PAD |
| Løsning | 1024×768 |
| Sammensætning | LCM |
| Lysstyrke | 300 |
| CR | 600:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | LG Display |
| panel model | LP097X02-SLQE 4 Compatible model |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 9.7 inch |
| løsning | 1024(RGB)×768 , XGA |
| visningstilstand | S-IPS, Normally Black, Transmissive |
| aktivt område | 196.608×147.456 mm |
| omrids | 210.32×164.37×5.23 mm |
| overflade | Glare (Haze 0%), Hard coating (3H) |
| lysstyrke | 300 cd/m² (Typ.) |
| kontrastforhold | 600:1 (Typ.) |
| vise farver | 262K (6-bit) |
| responstid | 35 (Typ.)(Tr+Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 6S6PWLEDWithout Driver |
| signal interface | LVDS (1 ch, 6-bit), 30 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | PAD |
| LP097QX1-SPC3 | LG Display | 9.7 | 2048×1536 |
| LP097X02-SLA2 | LG Display | 9.7 | 1024×768 |
| LP097X02-SLA3 | LG Display | 9.7 | 1024×768 |
| LP097X02-SLAA | LG Display | 9.7 | 1024×768 |
| LP097X02-SLG4 | LG Display | 9.7 | 1024×768 |
| LP097X02-SLN1 | LG Display | 9.7 | 1024×768 |
| LP097X02-SLQ1 | LG Display | 9.7 | 1024×768 |
| LP097X02-SLQA | LG Display | 9.7 | 1024×768 |
| LP097X02-SLQE | LG Display | 9.7 | 1024×768 |
| LTN097QL01-A02 | Samsung | 9.7 | 2048×1536 |
| B080EAN01.1 | AUO | 8.0 | 800×1280 |
| B116HAT03.1 | AUO | 11.6 | 1920×1080 |
| CLAA080WQ02 XG | CPT | 8.0 | 800×1280 |
| HSD101PWW1-G10 | HannStar | 10.1 | 1280×800 |
| LP101WH4-SLAB | LG Display | 10.1 | 1366×768 |
| LP101WX2-SLA1 | LG Display | 10.1 | 1280×800 |
| LQ097L1JY02Z | SHARP | 9.7 | 2048×1536 |
| LTN097XL01-A02 | Samsung | 9.7 | 1024×768 |
| LTN101AL03-801 | Samsung | 10.1 | 1280×800 |
| VVX09F035M20 | Panasonic | 8.9 | 1920×1200 |
