| Varenummer | AM-1024768Y2TZQW-A1H |
| Mærke | AMPIRE |
| Størrelse | 10.4 |
| Ansøgning | Industrial Outdoor H |
| Løsning | 1024×768 |
| Sammensætning | a-Si TFT-LCD, LCM |
| Lysstyrke | |
| CR | 900:1 |
| Farver | 16.2M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | AMPIRE |
| panel model | AM-1024768Y2TZQW-A1H |
| panelstørrelse | 10.4" |
| paneltype | a-Si TFT-LCD, LCM |
| løsning | 1024(RGB)×768, XGA, 123PPI |
| pixel format | RGB Vertical Stripe |
| udstillingsområde | 211.2(W)×158.4(H) mm |
| bezel åbning | 213.2(W)×160.4(H) mm |
| konturstørrelse | 236(W)×174.3(H) ×10.4(D) mm |
| overflade | Antiglare, Hard coating (3H) |
| lysstyrke | 1000 cd/m² (Typ.) |
| kontrastforhold | 900:1 (Typ.) (TM) |
| synsvinkel | 85/85/85/85 (Typ.)(CR≥10) |
| visningstilstand | IPS, Normally Black, Transmissive |
| bedste udsigt på | Symmetry |
| responstid | 30 (Typ.)(Tr+Td) |
| vise farver | 16.2M |
| lampe type | WLED , 30K hours , With LED Driver |
| frekvens | 60Hz |
| berøringsskærm | Without |
| panelvægt | TBD |
| Ansøgning | Industrial Outdoor High Brightness |
| signal interface | LVDS (1 ch, 8-bit) , 20 pins Connector |
| indgangsspænding | 3.3V (Typ.) |
| miljø | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
