| Varenummer | AM-480272MGTZQW-02H |
| Mærke | AMPIRE |
| Størrelse | 4.3 |
| Ansøgning | Industrial Outdoor H |
| Løsning | 480×272 |
| Sammensætning | a-Si TFT-LCD, LCM |
| Lysstyrke | |
| CR | 800:1 |
| Farver | 16.7M |
| Baggrundsbelysning | 5S3P |
| Interface | Parallel |
| panel mærke | AMPIRE |
| panel model | AM-480272MGTZQW-02H |
| panelstørrelse | 4.3" |
| paneltype | a-Si TFT-LCD, LCM |
| løsning | 480(RGB)×272, WQVGA, 128PPI |
| pixel format | RGB Vertical Stripe |
| udstillingsområde | 95.04(W)×53.856(H) mm |
| bezel åbning | 97.6(W)×56.0(H) mm |
| konturstørrelse | 105.6(W)×67.2(H) ×3.1(D) mm |
| overflade | - |
| lysstyrke | 1000 cd/m² (Typ.) |
| kontrastforhold | 800:1 (Typ.) (TM) |
| synsvinkel | 85/85/85/85 (Typ.)(CR≥10) |
| visningstilstand | IPS, Normally Black, Transmissive |
| bedste udsigt på | Symmetry |
| responstid | 30 (Typ.)(Tr+Td) |
| vise farver | 16.7M 51% NTSC |
| lampe type | 5S3P WLED , Without Driver |
| frekvens | 60Hz |
| berøringsskærm | Without |
| panelvægt | - |
| Ansøgning | Industrial Outdoor High Brightness Automotive Display |
| signal interface | Parallel RGB (1 ch, 8-bit) , 40 pins FPC |
| indgangsspænding | 3.3V (Typ.) |
| miljø | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
