| Varenummer | H429AL01 V0 |
| Mærke | AUO |
| Størrelse | 4.3 |
| Ansøgning | MPH |
| Løsning | 540×960 |
| Sammensætning | LCM |
| Lysstyrke | 500 |
| CR | 900:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | MDDI/MIPI |
| panel mærke | AUO |
| panel model | H429AL01 V0 |
| paneltype | LTPS TFT-LCD , LCM |
| panelstørrelse | 4.3 inch |
| løsning | 540(RGB)×960 , qHD |
| visningstilstand | MVA, Normally Black, Transmissive |
| aktivt område | 53.46×95.04 mm |
| omrids | 58.54×105.7 mm |
| overflade | |
| lysstyrke | 500 cd/m² (Typ.) |
| kontrastforhold | 900:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193170% |
| responstid | 20 (Typ.)(Tr+Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| lampe type | 10S1PWLEDWithout Driver |
| signal interface | MDDI/MIPI, 23 pins |
| indgangsspænding | 1.8/3.0V (Typ.)(VDDI/VCI) |
| Ansøgning | MPH |
