| Varenummer | AM-480272-043D |
| Mærke | Other |
| Størrelse | 4.3 |
| Ansøgning | CNS |
| Løsning | 480×272 |
| Sammensætning | LCM |
| Lysstyrke | |
| CR | |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | Amson |
| panel model | AM-480272-043D |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 4.3 inch |
| løsning | 480(RGB)×272 , WQVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 95.04×53.856 mm |
| omrids | 105.5×67.2×3.2 mm |
| overflade | |
| lysstyrke | |
| kontrastforhold | |
| vise farver | 16.7M (8-bit) |
| responstid | |
| synsvinkel | |
| lampe type | WLEDWithout Driver |
| signal interface | Parallel RGB (1 ch, 8-bit), 39 pins |
| indgangsspænding | 3.0V (Typ.) |
| Ansøgning | CNS |
| 43WQW1H | SII | 4.3 | 480×272 |
| A043FW02 V8 | AUO | 4.3 | 480×272 |
| AM-480272-043D | Other | 4.3 | 480×272 |
| DLC0430LZG-8 | Other | 4.3 | 480×272 |
| DLC0430LZG-T | Other | 4.3 | 480×272 |
| LB043WQ1-TD01 | LG Display | 4.3 | 480×272 |
| LMS430HF41-004 | Samsung | 4.3 | 480×272 |
| LQ043T3DX02 | SHARP | 4.3 | 480×272 |
| LQ043T3DX0G | SHARP | 4.3 | 480×272 |
| TD043MTEA2 | TPO | 4.3 | 800×480 |
| AM-1024600-070H | Other | 7.0 | 1024×600 |
| AT080TN42 | Innolux | 8.0 | 800×600 |
| CLAA069LA0ACW | CPT | 7.0 | 800×480 |
| CLAA070NJ07CW | CPT | 7.0 | 1024×600 |
| DD070NA-02A | Innolux | 7.0 | 800×480 |
| EDTCB18QEF | TOSHIBA | 7.0 | 800×480 |
| HSD070IFW1-A00 | HannStar | 7.0 | 1024×600 |
| LB058WQ1-SD02 | LG Display | 5.8 | 400×240 |
| LQ065Y5DG03 | SHARP | 6.5 | 800×480 |
| ND078-101A1 | SEBO | 7.8 | 1280×400 |
