| Varenummer | AMS529BY01 |
| Mærke | Samsung |
| Størrelse | 5.3 |
| Ansøgning | MPH |
| Løsning | 1080×1920 |
| Sammensætning | Assembly |
| Lysstyrke | 350 |
| CR | 60000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | self |
| Interface | MIPI |
| panel mærke | SAMSUNG |
| panel model | AMS529BY01 |
| paneltype | AM-OLED , Assembly |
| panelstørrelse | 5.3 inch |
| løsning | 1080RG(BG)×1920 , FHD |
| aktivt område | 65.88×117.12 mm |
| omrids | 76.4×142.2×2.1 mm |
| overflade | Hard coating (3H) |
| lysstyrke | 350 cd/m² (Typ.) |
| kontrastforhold | 60000 : 1 (Min.) |
| vise farver | 16.7M (8-bit), CIE1931100% |
| synsvinkel | 88/88/88/88 (Min.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| signal interface | MIPI (4 data lanes), 40 pins |
| indgangsspænding | 1.8/3.0/4.0V (Typ.)(VDD3/VCI/VBAT) |
| Ansøgning | MPH |
