| Varenummer | H466TAN01.0 |
| Mærke | AUO |
| Størrelse | 4.7 |
| Ansøgning | MPH |
| Løsning | 720×1280 |
| Sammensætning | LCM |
| Lysstyrke | 400 |
| CR | 900:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | MIPI |
| panel mærke | AUO |
| panel model | H466TAN01.0 |
| paneltype | LTPS TFT-LCD , LCM |
| panelstørrelse | 4.7 inch |
| løsning | 720(RGB)×1280 , WXGA |
| visningstilstand | AHVA, Normally Black, Transmissive |
| aktivt område | 58.104×103.296 mm |
| omrids | 61.92×114.38×1.75 mm |
| overflade | |
| lysstyrke | 400 cd/m² (Typ.) |
| kontrastforhold | 900:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193170% |
| responstid | 35 (Max.)(Tr+Td) |
| synsvinkel | 80/80/80/80 (Min.)(CR≥100)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDWithout Driver |
| signal interface | MIPI (3 data lanes), 25 pins |
| Ansøgning | MPH |
