| Varenummer | LQ047K3SX06 |
| Mærke | SHARP |
| Størrelse | 4.7 |
| Ansøgning | MPH |
| Løsning | 720×1280 |
| Sammensætning | LCM |
| Lysstyrke | 450 |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | MIPI |
| panel mærke | SHARP |
| panel model | LQ047K3SX06 |
| paneltype | IGZO TFT-LCD , LCM |
| panelstørrelse | 4.7 inch |
| løsning | 720(RGB)×1280 , WXGA |
| visningstilstand | New Mode2, Normally Black, Transmissive |
| aktivt område | 58.104×103.296 mm |
| omrids | 61.05×112.09×1.52 mm |
| overflade | Hard coating (3H) |
| lysstyrke | 450 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193170% |
| responstid | 30 (Typ.)(Tr+Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 10S1PWLEDWithout Driver |
| signal interface | MIPI (4 data lanes), 40 pins |
| indgangsspænding | 1.8/5.0/-5.0V (Typ.)(IOVCC/AVDD/AVEE) |
| Ansøgning | MPH |
