| Varenummer | LQ140Z1JW01 |
| Mærke | SHARP |
| Størrelse | 14.0 |
| Ansøgning | NBPC |
| Løsning | 3200×1800 |
| Sammensætning | LCM |
| Lysstyrke | 400 |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | eDP |
| panel mærke | SHARP |
| panel model | LQ140Z1JW01 |
| paneltype | IGZO TFT-LCD , LCM |
| panelstørrelse | 14.0 inch |
| løsning | 3200(RGB)×1800 , Quad-HD+ |
| visningstilstand | Normally Black, Transmissive |
| aktivt område | 309.6×174.15 mm |
| omrids | 320.65×199.08×2.75 mm |
| form stil | Slim (PCBA Flat, Depth ≤3.2mm) |
| overflade | Antiglare (Haze 42%) |
| lysstyrke | 400 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193172% |
| responstid | 25 (Typ.)(Tr+Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 8S8PWLEDWithout Driver |
| signal interface | eDP (4 Lanes), 50 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | NBPC |
| B140XTN03.1 | AUO | 14.0 | 1366×768 |
| B140XW02 V1 | AUO | 14.0 | 1366×768 |
| HB140WX1-200 | BOE | 14.0 | 1366×768 |
| HT140WXB-501 | BOE | 14.0 | 1366×768 |
| LP140WF1-SPJ1 | LG Display | 14.0 | 1920×1080 |
| LP140WH1-TLD6 | LG Display | 14.0 | 1366×768 |
| LP140WH4-TLB1 | LG Display | 14.0 | 1366×768 |
| LQ140Z1JW01 | SHARP | 14.0 | 3200×1800 |
| LTN140AT20-P02 | Samsung | 14.0 | 1366×768 |
| M140NWR1 R0 | IVO | 14.0 | 1366×768 |
| B156RW01 V0 | AUO | 15.6 | 1600×900 |
| LP133WX1-TLA1 | LG Display | 13.3 | 1280×800 |
| LP140WH1-TLC6 | LG Display | 14.0 | 1366×768 |
| LP154WX2-TL01 | LG Display | 15.4 | 1280×800 |
| LP156WD1-TLA2 | LG Display | 15.6 | 1600×900 |
| LQ106K1LA02 | SHARP | 10.6 | 1280×768 |
| LTN156AT05-H02 | Samsung | 15.6 | 1366×768 |
| LTN156AT19-001 | Samsung | 15.6 | 1366×768 |
| N156BGE-L41 | Innolux | 15.6 | 1366×768 |
| NT116WHM-N22 | BOE | 11.6 | 1366×768 |
