| Varenummer | B140XTN03.4 |
| Mærke | AUO |
| Størrelse | 14.0 |
| Ansøgning | NBPC |
| Løsning | 1366×768 |
| Sammensætning | LCM |
| Lysstyrke | 200 |
| CR | 500:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | eDP |
| panel mærke | AUO |
| panel model | B140XTN03.4 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 14.0 inch |
| løsning | 1366(RGB)×768 , WXGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 309.399×173.952 mm |
| omrids | 320.4×205.1×3.6 mm |
| form stil | Flat (PCBA Flat, Depth 3.4~4.0mm) |
| overflade | Glare (Haze 0%), Hard coating (3H) |
| lysstyrke | 200 cd/m² (Typ.) |
| kontrastforhold | 500:1 (Typ.) |
| vise farver | 262K (6-bit), CIE193160% |
| responstid | 8 (Typ.)(Tr+Td) |
| synsvinkel | 45/45/15/35 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDEmbedded (LED Driver) |
| signal interface | eDP (1 Lane), 30 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | NBPC |
| B140XTN02.3 | AUO | 14.0 | 1366×768 |
| B140XTN03.2 | AUO | 14.0 | 1366×768 |
| B140XTN03.4 | AUO | 14.0 | 1366×768 |
| B140XTN03.5 | AUO | 14.0 | 1366×768 |
| B140XTN03.9 | AUO | 14.0 | 1366×768 |
| B140XW01 V0 | AUO | 14.0 | 1366×768 |
| B140XW01 V8 | AUO | 14.0 | 1366×768 |
| B140XW02 V0 | AUO | 14.0 | 1366×768 |
| B140XW02 V2 | AUO | 14.0 | 1366×768 |
| B140XW03 V0 | AUO | 14.0 | 1366×768 |
| B156HW01 V0 | AUO | 15.6 | 1920×1080 |
| LP141WP2-TLA1 | LG Display | 14.1 | 1440×900 |
| LP154WX7-TLB3 | LG Display | 15.4 | 1280×800 |
| LP156WH4-TLN1 | LG Display | 15.6 | 1366×768 |
| LTD089EXWS | TOSHIBA | 8.9 | 1280×768 |
| LTM09C362F | TOSHIBA | 8.9 | 1024×600 |
| LTM12C505T | TOSHIBA | 12.1 | 1024×768 |
| LTN154AT01-A01 | Samsung | 15.4 | 1280×800 |
| LTN184KT01-101 | Samsung | 18.4 | 1680×945 |
| N154I6-L03 | Innolux | 15.4 | 1280×800 |
